Prototype PCB Assembly
Prototype PCB Assembly is a specialized service offered by Bester, catering to the unique needs of our customers in the printed circuit board industry. As the name suggests, this service focuses on the production of custom-made prototypes of PCBs, which are essential for testing and validating new electronic designs before they are mass-produced. With our expertise and state-of-the-art equipment, we ensure that these prototypes are assembled with utmost precision and accuracy, adhering to industry standards and specific customer requirements. Our experienced team of professionals meticulously handles the entire assembly process, from sourcing the components to soldering them onto the PCBs, ensuring that each prototype is meticulously crafted to meet the highest quality standards. By availing our Prototype PCB Assembly service, customers can significantly reduce time-to-market, minimize design errors, and gain valuable insights into the functionality and performance of their electronic products.
PCB Assembly Process
One of the most important factors in the overall efficiency of each PCB assembly project is the client’s understanding of our process. The number of steps involved in the PCB assembly process depends upon the specific nature of the project in question, as illustrated below, and each of these steps is explained briefly in the following sections.
DFM Check
DFM checks our client’s PCB design and looks for issues that may influence the final product negatively, such including missing, redundant or potentially problematic features. And the consistency across different design documents like BoM and Gerbers.
IQC
Inspect all incoming materials and handle quality problems before the SMT assembly process. Bester IQC and procurement team will check for model numbers, shape, sample test, etc to ensure all parts used are of the highest quality.
Solder Paste Printing
Solder paste printing is the actual first step in PCB assembly manufacturing process that can apply solder paste to the appropriate, necessary areas on the PCB using stencil and squeegees.
SMD Components assembly
Pick and Place SMD components to the programmed location at high speed using automated Pick&Place machines after solder paste is correctly applied to bare PCBs.
Reflow Soldering
After SMD components are placed on the boards, they are sent through reflow machines to have the solder paste to reflow, attach components and create permanent solder joints.
THT Components Assembly
Pick and Place THT components to the programmed location at high speed using automated Pick&Place machines for the wave soldering process.
wave soldering
Wave soldering is a method of PCB Assembly that involves sending boards on a conveyor through a wave of molten solder that is used to attach through-hole components to the boards.
AOI & X-ray
Inspect and verify that no mistakes have been made and that all parts have been correctly placed using automated optical inspection(AOI) and X-Ray technology and machines.
Final inspection & repairing
The final inspections include visual inspection by our quality assurance team and post AOI inspection for flaws and functions. It’s also known as functional test.
QC / packaging
All assembled boards are packaged per clients’ request in anti-static packaging and be prepared for shipping under our QC team.
PCBA Capabilities
- Types of Assembly
-
THD (Thru-Hole Device)
SMT (Surface-Mount Technology)
SMT & THD mixed
2 sided SMT and THD assembly - Types of PCB
- Rigid, Flexible, Rigid-Flex PCBs, MC PCBs, Ceramic PCBs, Rogers PCBs
- Board Dimensions
-
Smallest size: 0.2″ x 0.2″
Largest size: 15″ x 20″White, Yellow, Black (Inquire for more options) - Board Shape
- Rectangular
Round
Slots and Cut outs
Complex and Irregular - Board Type
- Rigid FR-4
Rigid-Flex boards - Design File Format
- Gerber RS-274X
BOM (Bill of Materials) (.xls, .csv, . xlsx)
Centroid (Pick-N-Place/XY file) - Assembly Process
- Leaded process
Lead-Free (RoHS) - Components
- Passives parts, smallest size 0201
Fine pitch to 8 Mils
BGA, uBGA, QFN,POP and Leadless chips
Connectors and terminals - Component Package
- Reels
Cut tape
Tube and tray
Loose parts and bulk - Parts Procurement
- Full Turnkey, Partial Turnkey, Consigned/kitted
- Component Size
- Smallest Components, Micro BGA, Fine Pitch Parts Assembly
- Stencils
- Nano-coating, Laser-cut stainless steel
- Soldering
- Reflow Soldering, Wave Soldering
- Testing Method
- AOI (Automated Optical Inspection)
Visual inspection
X-Ray Inspection
Flying Probe testing
ICT Testing
Functional Testing - Repair & Rework
- Ball Grid Array replacement, IR rework
- Turnaround Time
- 1-5 days for only PCB assembly
10-16 days for turnkey PCB assembly - Production Capacity
- 4 SMT lines, 2 DIP Production Lines, 20 Automatic Robotic Soldering Lines
Why Choose Bester
Strong Assembly Capacities
With state-of-the-art facilities and a highly skilled team, we have the capacity to handle even the most complex PCB assembly projects, ensuring your products are manufactured efficiently and accurately.
Quality Assurance
Our rigorous quality control processes and extensive testing procedures guarantee that every PCB assembly we produce meets the highest industry standards for reliability and performance, giving you peace of mind and confidence in our services.
One-stop Service
From PCB fabrication and design to component sourcing and IC programming, Bester offers a comprehensive range of services under one roof, streamlining the production process and saving you time and effort.
Fast Turnaround
Our commitment to fast turnaround times means that your PCB assembly projects will be completed on schedule, allowing you to meet your production deadlines and get your products to market quickly.
